U-981 USB 3.0 Gigabit Ethernet Adapter
Get a Quote ✎
2020/11/02
- 1GbE RJ45 Port
- Wake-on-LAN
- USB 5Gbps Type-A Male Upstream Port
- Ordering Code: U-981
- Part No: U3-R28-LN10-11-00012
- Solution: Realtek RTL8153B
The U-981 USB 3.0 Gigabit Ethernet Adapter adds a reliable RJ-45 Ethernet port to any USB-enabled computer, delivering network speeds of up to 1000 Mbps. Powered by the advanced Realtek RTL8153B chipset, it offers lower power consumption than the previous RTL8153, making it especially well-suited for laptops, tablets, and other portable devices. Fully backward compatible with USB 2.0 systems and supporting 10/100 Mbps Ethernet networks, this compact and lightweight adapter is the perfect solution for replacing a desktop network card or enhancing mobile connectivity on the go.
Features
- Compliant with USB 3.0，USB 2.0 and USB 1.1
- Supports 10/100/1000 Mbps Ethernet
- Supports IEEE 802.1Q VLAN tagging
- Supports IEEE 802.3az (Energy Efficient Ethernet)
- Supports Full Duplex flow control (IEEE 802.3 x)
- Supports Wake-on-LAN
- Downstream port: RJ45
- Up to 9KB jumbo frames
| Ordering Code | U-981 |
|---|---|
| Description | USB 3.0 Gigabit Ethernet Adapter |
| Solution | Realtek RTL8153B |
| Standard Compliance | USB 3.0 1 GBASE-T |
| Bus Type | USB 5Gbps |
| OS Driver Support | Windows XP/7/8/8.1/10/11 (32/64 bit) Mac OS 10.6 and later Linux 2.6.27 and later |
| Connectors | 1x 1GbE RJ45 Port |
| Data Rates | 1Gb/100Mb/10Mb Ethernet |
| Operating Temperature | 0℃ – 40℃ |
| Storage Temperature | 0℃ – 50℃ |
| EMC Standards | CE, FCC |
| Dimensions | 75.4L x 27.4W x 16H mm | Cable 150mm |
| Package content | 1x USB 3.0 Gigabit Ethernet Adapter 1x User Manual |
| Packing Information | Retail Box Packing 40 pcs/Carton Measurment: 44.5L x 42W x 29.3H cm G.W: 4 Kg ; N.W: 3.3 Kg |
Manual :
U-981 User Manual
↧ DownloadDriver :
RTL_USB_ FE_GBE_Linux.zip
↧ DownloadRTL_USB_ FE_GBE_Windows.zip
↧ DownloadRTL_USB_ FE_GBE_Mac.zip
↧ Download
