U-2110 USB 5Gbps Type-C Multiport Adapter w/PD

Get a Quote ✎

2020/05/20

1x HDMI™ Port UHD 3840x2160 @30Hz
2x USB 5Gbps Type-A Ports
1x USB 5Gbps Type-C Port
1x USB Type-C PD pass-through Port

Ordering Code: U-2110
Part No: U3-C56-DS10-11-00012
Solution: CH7210A + VL817

This USB-C Multiport Adapter connects your MacBook or Windows laptop to your monitor through USB Type-C (DP) port. It doesn't require any extra drivers, just plug-and-play.

Features

Work with USB Type-C laptop
Support 60W Power Delivery Passthrough laptop charging
Compliant with HDMI 2.0, HDMI 1.4
HDMI port supports UHD 3840x2160@30Hz
Compliant with USB 3.2 Gen 1 and data rate up to 5Gbps
Provide two Type-A and one Type-C downstream ports
Support Hot Plug Detection
No need to install drivers

Ordering Code	U-2110
Description	USB 5Gbps Type-C Multiport Adapter w/PD
Solution	CH7210A + VL817
Bus Type	USB 5Gbps
OS Driver Support	OS independent with no drivers required Requires DisplayPort Alternate Mode capability
Connectors	1x HDMI™ Port 2x USB 5Gbps Type-A Ports 1x USB 5Gbps Type-C Port 1x USB Type-C PD Port
Data Rates	USB 5Gbps
Resolution	3840x2160 @30Hz
Power Delivery	PD pass-through
Operating Temperature	0℃ – 45℃
Storage Temperature	-10℃ – 50℃
EMC Standards	CE, FCC
Dimensions	56.1L x 94.6W x 17.8H mm \| Cable 150mm
Package content	1x USB 5Gbps Type-C Multiport Adapter w/PD 1x User Manual
Packing Information	Retail Box Packing 40 pcs/Carton Measurment: 40L x 36W x 31H cm G.W: 5.3 Kg ; N.W: 4.8 Kg
