U-2080 USB 5Gbps Type-C Multiport Adapter w/ PD
Get a Quote ✎
2020/05/20
- 1x VGA port
- 1x USB 5Gbps Type-A port
- 1x USB Type-C PD port
- PD pass-through
- Ordering Code: U-2080
- Part No: U3-K12-DS10-11-00012
- Solution: CH7212A
Connect your Macbook or tablet to your display through your USB Type-C (DP) port using this adapter. Doesn't require any extra drivers, just plug-and-play. Requires DisplayPort Alternate Mode capability.
Features
- Works with USB Type-C laptop
- Simultaneously display via VGA outputs
- Supports Hot Plug Detection
- NO need to install driver
- USB Type-C port with DisplayPort video signal
- Note: USB Type-C port that transmits data signal without DisplayPort video signal is not supported
| Ordering Code | U-2080 |
|---|---|
| Description | USB 5Gbps Type-C Multiport Adapter w/ PD |
| Solution | CH7212A |
| Bus Type | USB 5Gbps |
| OS Driver Support | Windows 7/8/8.1/10(32/64 bit) Mac OS X v10.8 or later Linux 2.6.24 and 4.11.x or later |
| Connectors | 1x VGA port 1x USB 5Gbps Type-A port 1x USB Type-C PD port |
| Power Delivery | PD pass-through |
| Operating Temperature | 0℃ – 45℃ |
| Storage Temperature | -10℃ – 50℃ |
| EMC Standards | CE, FCC |
| Dimensions | 50L x 82W x 16.6H mm | Cable 150mm |
| Package content | 1x USB 5Gbps Type-C Multiport Adapter w/ PD 1x User Manual |
| Packing Information | Retail Box Packing 40 pcs/Carton Measurment: 35L x 28W x 23H cm G.W: 4.7 Kg ; N.W: 4.2 Kg |
Manual :
U-2080 User Manual
↧ DownloadDriver :
No Driver Required
