U-2010 USB 5Gbps Type-C Multiport Adapter w/ PD
Get a Quote ✎
2019/10/28
- 1x USB 5Gbps Type-A Port
- 1x HDMI Port
- 1x USB Type-C PD Port
- PD pass-through
- Ordering Code: U-2010
- Part No: U3-K13-DS10-11-00012
- Solution: CH7210A
Connect your Macbook or tablet to your HDMI display through your USB Type-C (DP) port using this adapter. Doesn't require any extra drivers, just plug-and-play. Requires DisplayPort Alternate Mode capability.
Features
- Works with USB Type-C enabled smartphone, tablet or computer
- Supports resolution up to 3840x2160@30Hz
- 1x USB 3.1 Gen 1 Type-A port for data
- Supports upstream charging of laptop
- Requires Type-C DisplayPort Alt Mode
| Ordering Code | U-2010 |
|---|---|
| Description | USB 5Gbps Type-C Multiport Adapter w/ PD |
| Solution | CH7210A |
| Bus Type | USB 5Gbps |
| OS Driver Support | OS independent with no drivers required Requires DisplayPort Alternate Mode capability |
| Connectors | 1x HDMI™ Port 1x USB 5Gbps Type-A Port 1x USB Type-C PD Port |
| Data Rates | USB 5Gbps |
| Resolution | 3840x2160 @30Hz |
| Power Delivery | PD pass-through |
| Operating Temperature | 0℃ – 45℃ |
| Storage Temperature | -10℃ – 50℃ |
| EMC Standards | CE, FCC |
| Dimensions | 53L x 64W x 16.6H mm | Cable 150mm |
| Package content | 1x USB 5Gbps Type-C Multiport Adapter w/ PD 1x User Manual |
| Packing Information | Retail Box Packing 40 pcs/Carton Measurment: 40L x 36W x 31H cm G.W: 5.3 Kg ; N.W: 4.8 Kg |
