N-950 PCIe 2-Port 5G 5-Speed Multi-Gigabit Network Adapter
Get a Quote ✎
2024/01/15
- 2x 5GbE RJ45 Ports
- PCIe 3.0 x2 Form Factor
- Wake-On-LAN
- Ordering Code: N-950
- Part No: NE-R31-2210-00-00012
- Solution: Realtek RTL8126
This specification defined a high performance PCIe Ethernet adapter which provides two RJ-45 ports for network connection of data rate up to 5Gbps. The PCIe Gen3 x2 interface enables running at maximum full duplex throughput as well as backward compatible with Gen1/2 PCIe slots. With this adapter, the network environment permits easy upgrade to 5Gbps network bandwidth over existing Cat 5E network cabling.
Features
- PCIe Gen3 x2 form factor
- Supports standard and low profile systems
- Supports 5-speed 5G/2.5G/1G/100M/10Mbps auto negotiation
- Runs 5Gbps on Cat 5E cable up to 100m
- Supports Wake-On-LAN (WoL)
- Up to 16KB jumbo frame
- Checksum and TSO offload
- Network ARP and NS offload
- Green LEDs indicate status of Link/Activity
| Ordering Code | N-950 |
|---|---|
| Description | PCIe 2-Port 5G 5-SpeedMulti-Gigabit Network Adapter |
| Solution | Realtek RTL8126 |
| Form Factor | PCIe 3.0 x2 |
| Bus Width | x2 lane PCI Express |
| OS Driver Support | Windows 11/10 Linux kernel 3.10 or later |
| Connectors | 2x 5GbE RJ45 Ports |
| Data Rates | 5Gb/2.5Gb/1Gb/100Mb/10Mb Ethernet |
| Support Low-Profile Bracket | Yes |
| Operating Temperature | 0°C – 55°C |
| Storage Temperature | -20°C – 70°C |
| EMC Standards | CE, FCC |
| Dimensions | 133.3L x 120.9W x 21.6H mm |
| Package Contents | 1x PCIe 2-Port 5G 5-SpeedMulti-Gigabit Network Adapter 1x Low-Profile Bracket 1x User Manual |
| Packing Information | Retail Box Packing 20 pcs/Carton Measurment: 36L x 30W x 23H cm G.W: 3.8 Kg ; N.W: 3.3 Kg |
